产品概述：

黄酒过滤机系引进国外先进技术，选用优质不锈钢制作，采用硅藻土为助滤剂。促进我国黄酒行业从陈旧的棉饼过滤工艺向世界先进行列迈进了一大步。它具有外形美观、操作简便、过滤陈本低、效率高等特点，过滤澄清度可达99.8%，操作得法，能滤除1-0.1微米以下的微粒，甚至可滤除大肠杆菌。

料液经硅藻土过滤后，风味不变，无悬浮物和沉淀物，澄清透明、滤清度高，液体损失小。

该机已在黄酒、白酒、果酒、清酒等行业广泛应用，并获得好评，我公司愿为您在过滤工序中取得良好的效果而努力！

PRODUCT OVERVIEW:

Yellow wine filter imports foreign advanced technology and uses the high-quality stainless steel with diatomite as filter aids. It promotes yellow wine industry a big step from old mianbing filtering process to world’s advanced ranks. It has characteristics like beautiful appearance，easy operation，low filtering cost，high efficiency and so on. Filtering clarity can reach 99.8%. When managed correctly, it can remove particle under 1-0.1 um and even can remove escherichia coil.

After filtration of diatomite, the feed liquid keeps flavor constant without the suspended matter and sediment. The liquid is clear& colorless, has high filtration degree and small liquid loss.

This machine is widely used in yellow wine, white wine, fruit wine and sake industry, and has gained critical praise, our company would like to try hard for you achieving good effect.

工作原理：

过滤时，首先在滤液表面形成均匀的硅藻土预涂层，以恒定的速度均匀地进行预涂，待滤液体经过硅藻土预涂层时，杂质被截挡，清液经硅藻土孔径及颗粒之间的间隙通过预涂层，从而得到澄清的液体。

随着过滤时间的推移，在预涂层上被滤掉的杂质会越来越多，且将阻塞过滤通道，因此需添加一定数量的硅藻土，让硅藻土随同被滤液中的悬浮固物，能同时被虑网留和吸附，形成新虑层，不让新虑层的微虑孔给全部堵塞，保持过滤性能，从而延长虑程周期，增加一次过滤总量。

过滤时如需对被虑液体进行脱色，可增减一定比例的活性炭，从而达到脱色的效果。

Working principle：

When filtering,form uniform diatomite pre-coating on the filter leaf surface at first and carry out the uniform pre-coating with constant speed evenly；when filtrate body goes through diatomite pre-coating，impurity is cut in and the clear liquid passes through the  pre-coating by diatomite aperture and space between particles so as to clarify the liquid. Along with the filtration time,impurity will be more and more on the pre-coating and the filter channel will be blocked. Therefore it is needed to add a certain amount of diatomite.The diatomite and the suspended solid content in the filtrate can also be left and adsorbed by the filtering net at the same time to form the new filter layer. All these micro filter holes of the new filter layer can’t be blocked and the filtration performance shall be kept,so the filter period can be extended and one total filter volume can be added.When filtering ,if you need decoloring for the filtrate body,the activated carbon of one certain scale can be increased to reach the effect of decolorization.

Our company can also provide all kinds of rice grinding mixing machine for you at the same time！
