应用：用于各种浮液的固液分离，适用范围广，应用于医药、化工、食品、环保、水处理、电子、纺织、电镀等相关行业。
工作原理：
悬浮液用泵送入滤机每个密闭的滤室，在压力的作用下，滤液透过滤层及滤膜和其他滤材，经膜口排除，滤渣则留在板框内形成滤饼，从而达到固液分离的目的。
Application:Use for solid-liquid separation of various floats, it is widely used in many industries,as Medical、Chemical industry、foodstuff、environment protection、Water treatment、Electronics、Textile、Electroplate and other relative industries.
Work principle:Suspensions will be put into the hermetic straining chamber by pump，at the function of the press，Suspension will flow through the filter layer，filter membrane and other filter materials，flow out through the filter membrane then，the filter residue will be left and become filter cake in the sheet frame，so Purpose for the solid-liquid separation will be come true.
技术参数：TECHNICAL DATA：
|
规格型号 Model |
滤板层数 Filter QTY |
过滤面积 Filtration Area(m2) |
滤材尺寸 Filter Size(mm) |
滤膜孔径 Filter Aperture(um) |
过滤压力 Filtering Pressure(Mpa) |
水流量 Flow(t/h) |
电机功率 Motor Power(Kw) |
外形尺寸 Dimension(mm) |
进口 Inlet (ɸmm) |
出口 Outlet (ɸmm) |
|
CR100-10 |
10 |
0.078 |
ɸ100 |
0.8 |
0.15 |
0.80 |
0.55 |
600*300*600 |
15 |
15 |
|
CR150-10 |
10 |
0.170 |
ɸ150 |
0.8 |
0.15 |
1.50 |
0.55 |
650*380*600 |
20 |
15 |
|
CR200-10 |
10 |
0.340 |
ɸ200 |
0.8 |
0.15 |
2.00 |
0.55 |
650*400*650 |
20 |
15 |
|
CR300-10 |
10 |
0.700 |
ɸ300 |
0.8 |
0.20 |
4.00 |
1.10 |
700*500*800 |
25 |
20 |
|
CR300-20 |
20 |
1.400 |
ɸ300 |
0.8 |
0.20 |
8.00 |
1.10 |
800*500*800 |
38 |
25 |
|
CR300-30 |
30 |
2.100 |
ɸ300 |
0.8 |
0.20 |
10.00 |
1.10 |
900*500*800 |
38 |
25 |
|
CR400-10 |
10 |
1.250 |
ɸ400 |
0.8 |
0.20 |
6.00 |
1.10 |
900*600*1000 |
38 |
25 |
|
CR400-16 |
16 |
2.000 |
ɸ400 |
0.8 |
0.20 |
9.00 |
1.50 |
1000*600*1000 |
38 |
25 |
|
CR400-20 |
20 |
2.500 |
ɸ400 |
0.8 |
0.20 |
10.00 |
1.50 |
1100*600*1000 |
38 |
25 |
|
CR400-24 |
24 |
3.000 |
ɸ400 |
0.8 |
0.30 |
12.00 |
2.20 |
1200*600*1000 |
38 |
25 |
|
CR400-30 |
30 |
3.800 |
ɸ400 |
0.8 |
0.30 |
16.00 |
2.20 |
1300*600*1000 |
45 |
25 |
|
CR400-32 |
32 |
4.000 |
ɸ400 |
0.8 |
0.30 |
18.00 |
2.20 |
1320*600*1000 |
45 |
25 |
|
BAS200-10 |
10 |
0.400 |
200*200 |
0.8 |
0.15 |
3.00 |
1.10 |
650*380*650 |
15 |
15 |
|
BAS300-10 |
10 |
0.900 |
300*300 |
0.8 |
0.15 |
6.00 |
1.10 |
700*500*800 |
20 |
15 |
|
BAS400-10 |
10 |
2.000 |
400*400 |
0.8 |
0.15 |
10.00 |
1.50 |
900*600*1000 |
20 |
15 |
|
BAS400-20 |
20 |
3.000 |
400*400 |
0.8 |
0.15 |
12.00 |
2.20 |
1100*600*1000 |
25 |
20 |
|
BAS400-26 |
26 |
4.000 |
400*400 |
0.8 |
0.20 |
15.00 |
2.20 |
1150*600*1000 |
38 |
25 |
|
BAS400-32 |
32 |
5.000 |
400*400 |
0.8 |
0.20 |
18.00 |
2.20 |
1200*600*1000 |
38 |
25 |
|
BAS400-38 |
38 |
6.000 |
400*400 |
0.8 |
0.30 |
21.00 |
2.20 |
1300*600*1000 |
38 |
25 |
|
BAS400-44 |
44 |
7.000 |
400*400 |
0.8 |
0.30 |
24.00 |
3.00 |
1360*600*1000 |
38 |
25 |
